PVC LT Underground Cables

Why Choose Us?

Durable, cost-effective PVC-insulated cables designed for low-voltage underground power distribution up to 1.1 kV. Available in single- and multi-core armoured variants, these cables deliver proven performance and safety in residential, commercial, and industrial installations.

Reliable Insulation

 PVC Type C (IS 5831) offers stable dielectric strength in varied high temperature conditions.

Mechanical Protection

 Galvanized steel strip/wire armour guards against external damage.

Flame-Retardant Options

IS 1554 (Part 1) is still valid but largely superseded by IS 7098 (Part 1); mention both for clarity.

Environmental Resistance

Environmental Resistance: Resistant to most oils, chemicals, and water, ideal for burial and duct installations.

Flexible Installation

 Stranded conductors and 12× diameter minimum bending radius simplify routing and jointing.

Cost-Effective

Optimized design for economical low-voltage networks without compromising on durability.

Applications

  • Underground power distribution in homes, offices, and factories
  • Cable trenches, duct banks, and direct burial installations
  • Utility feeder lines in substations and power plants
  • Mechanical-protection-critical circuits in outdoor and semi-outdoor settings
  • Low-voltage networks up to 1.1 kV across residential and commercial zones

Applicable Standards

  • IS 7098 – PVC-insulated cables for rated voltages up to 1.1 kV
  • IS 8130 – Aluminium and copper conductor specifications
  • IS 1554 – Power cables with extruded insulation for rated voltages up to 30 kV
  • IEC 60332 – Tests on electric‐cable flame propagation

Technical Specifications

Parameter Specification
Conductor Aluminium or Copper (solid/stranded) per IS 8130
Insulation PVC Type A per IS 5831
Inner Sheath Extruded PVC
Armour Galvanized steel strip/wire; aluminium for 1-core
Outer Sheath PVC-ST1/ST2 (flame-retardant optional)
Voltage Rating 1.1 kV AC
Test Voltage 3 kV for 5 min
Operating Temperature –15 °C to +70 °C
Short-Circuit Temp. Up to 250 °C for 5 s (XLPE)
Min. Bending Radius 12 × overall cable diameter
Available Sizes & Ratings
 4 sq.mm to 500 sq.mm; diameters 10.5 mm–74 mm; current ratings 50 A–850 A; short-circuit ratings up to 47.2 kA (Values depend on installation method; shown ratings are typical.)
