All-Aluminium Alloy Conductors

Why Choose Us?

Engineered from Aluminium Alloy 6201-T81, our AAAC range delivers superior strength and exceptional corrosion resistance, ideal for reliable overhead power distribution in harsh environments.

High Mechanical Strength

 Alloy composition and T81 temper provide low-sag performance over long spans.

Excellent Conductivity

Optimized DC resistance ensures efficient power transfer with minimal losses.

Corrosion Resistance

All-alloy construction withstands coastal, industrial, and urban pollutants.

Flexible Handling

Can be bent safely for easy stringing and installation.

Long Service Life

 Proven alloy stability maintains performance in extreme temperatures and weather.

Standard & Custom Sizes

 From smaller 30 kcmil “Akron” conductors up to 927 kcmil “Greeley,” or tailor-made to your specs.

Applications

  • Overhead transmission and distribution lines
  • Coastal and industrial zone networks
  • Rural electrification and long-span crossings
  • Retrofit projects on existing towers
  • Renewable energy evacuation (solar, wind farms)

Applicable Standards

  • IS 398-Part 4 – Aluminium alloy conductors for overhead lines
  • IEC 60889 – Applicable for aluminium alloy conductors, including reinforced and compacted types
  • ASTM B399 – Standard specification for aluminium‐alloy conductors, concentric‐lay strand
  • BS EN 50183 – Aluminium alloy conductors for overhead lines

Technical Specifications

Animal Name AWG/MCM Equiv. Stranding DC Resistance (Ω/km) Min. Breaking Strength (kN)
Rabbit 2/0 7 x 0.1488" 1.4635 23.74
Dog 266.8 19 x 0.128" 2.106 46.45
Panther 556.5 19 x 0.185" 3.041 96.98
Zebra 795 37 x 0.158" 3.635 134.69
Full size range from 30 kcmil to 927 kcmil. Custom stranding and reel-lengths available on request.
