Aluminum Conductors Steel Supported – Trapezoidal

Why Choose Us?

High-capacity, low-sag overhead conductors featuring trapezoidal aluminium strands compacted over a galvanized steel core, combining exceptional ampacity, mechanical strength, and thermal performance for today’s demanding transmission needs.
Trapezoidal Strand Design

Trapezoidal Strand Design

 Compact aluminium layers maximize packing density and reduce conductor diameter.
Steel Supported Core

Steel-Supported Core

Galvanized steel core delivers high tensile strength with minimal weight penalty.
Frame 122

Elevated-Temperature Rating

 Continuous operation up to 200 °C boosts ampacity by up to 50 % over conventional ACSR.
Low Sag

Low Sag Performance

 High modulus steel and controlled aluminium alloy minimize elongation under load.
Corrosion Resistance

Corrosion Resistance

All-aluminium exterior resists moisture, pollutants, and UV exposure.
Extended Service Life

Extended Service Life

 All-aluminium sheath resists UV and industrial atmospheres, minimizing maintenance needs .

Applications

  • Long-span transmission crossings (valleys, rivers)
  • High-temperature operation on existing lines to increase capacity
  • Renewable energy evacuation (solar and wind farms)
  • Urban network reinforcement where right-of-way is limited
  • Retrofit projects upgrading aging infrastructure without tower replacement
passing down1

Applicable Standards

  • IS 398 Part 2 – Aluminium alloy conductors for overhead lines
  • IEC 61089 – Round-wire concentric-lay overhead electrical conductors
  • ASTM B399 – Specification for aluminium-alloy conductors, concentric-lay strand
  • IEEE 738 – Calculation of temperature-rise in bare overhead conductors
Frame 1283

Technical Specifications

Code Word Size (kcmil) Diameter (in) Total Weight (lb/1,000 ft) Std Strength (lbs) DC Resistance @20 °C (Ω/1,000 ft) AC Resistance @75 °C (Ω/1,000 ft)
Flicker 477.0 0.4233 612.8 13,000 0.0354 0.0434
Hawk 477.0 0.4356 655.0 15,600 0.0352 0.0433
Parakeet 556.5 0.4937 714.9 15,200 0.0302 0.0372
Dove 556.5 0.5083 764.5 18,200 0.0301 0.0371
