AAC (All Aluminium Conductor)

AAC conductors are manufactured using an E C Grade aluminium where a 99.7% purity is maintained to the minimum while offering it in a wide variety as well. The high degree of resistance that it offers makes is suitable to be used in coastal areas where other materials are corroded easily. This also is very effective and useful in the areas where space is an issue; it has found its position well established in the Urban Areas due to the same reasons. The design is flexible as per the usage requirement of the conductors; to deliver in both a single and multi-strands.


AAC

Technical Data

Code Word Aluminium Area mm² Stranding & Wire Diameter mm Approx Over all Dia mmress Approx Mass Kg/Km Calculated Resistance at 20 C Max / KM Approx Calculated Breaking Load KN Approx. Calculated Breaking Load (kN)
Gnat 25 7/2.21 6.63 74 1.093 4.52 4.52
Ant 50 7/3.10 9.30 145 0.556 8.25 8.25
Wasp 100 7/4.39 13.17 290 0.277 15.96 15.96
Special 150 19/3.18 15.90 415 0.915 23.28 23.28
Spider 240 19/3.99 19.95 654 0.1244 35.74 35.74
Butterfly 300 19/4.65 23.25 888 0.01971 48.74 48.74
